Rugged Tablet Windows

Home > Products > Intelligent Device > Rugged Tablet > Rugged Tablet Windows

  • 8-Inch Rugged Tablet with Windows 10
  • 8-Inch Rugged Tablet with Windows 10
  • 8-Inch Rugged Tablet with Windows 10
  • 8-Inch Rugged Tablet with Windows 10

8 inch Rugged Tablet Windows 10 with Barcode Scanner

Quick Details:

CPUIntel Baytrail-T, Z3735FRAM2GB
Hard Disk64GBScreen8"
Brightness450nitsTouch TypeCapacitive
Battery3.7V/6000mAhIP GradeIP65


8-Inch Rugged Tablet with Windows 10 and Barcode Scanner


Introduction


Welcome to our comprehensive guide on the 8-inch rugged tablet with Windows 10 and a built-in barcode scanner. At [Our Company Name], we understand the importance of finding the right rugged tablet that meets your business needs while ensuring optimal performance and durability. In this article, we will delve into the key features, benefits, and applications of this remarkable device, providing you with the necessary information to make an informed decision. If you are interested in our Intelligent Device, feel free to contact us!


Details


1. support windows 10 system;

2. support standard USB2.0 port;

3. support docking charging docking extension;

4. support NXP NFC(13.56M);

5. support GPS navigation;

6. support 1D barcode scanner/2D barcode scanner;

7. rugged IP65 grade;

8. support strap.


R-I81EKF


Model:R-I81EKF
PC
CPUIntel Baytrail-T(Quad-core ),Z3735F, 1.33 GHz-1.83 GHz
GPUIntel® HD Graphics
RAM2GB
SSD64GB
G_sensorG_sensor
NFCOptional: NXP NFC 13.56MHz  support ISO/IEC 下14443A/14443B/15693/18092/mifare protocol,identification distance :2-4cm
WIFIAP6255 WIFI 802.11b/g/n/ac   frequency 2.4G+5.8G
BluetoothBT4.2 (BLE) class1  transmited distance:10m
(Bluetooth 5.1 Optional)
3GIC:H350_A30 frequency:WCDMA(900/2100MHz)  GSM(900/1800MHz),HSDPA 7.2Mbps,HSUPA 5.76 Mbps
4GEC25-E: LTE FDD: B1/B3/B5/B7/B8/B20 LTE TDD: B38/B40/B41 WCDMA: B1/B5/B8 GSM: B3/B8
GPSU-blox NEO-7,support :GPS;Capture sensitivity: -160 dBm;Cool Start Time:<50 seconds,Hot start time:<28 seconds,frequency:0.25 Hz … 10 MHz (configurable)
Camerafront 2.0MP with indicator light, rear 5.0MP
SpeakerEmbedded 8Ω/0.8W waterproof speaker*1
MicSensitivity: -42db, Output resistance: 2.2kΩ
Operation Systemwindows 10 S mode/ Pro 32bit 64bit
LCD panel
Panel size8"
Resolution800*1280 IPS
Aspect ratio16:10
Brightness (cd/m²)450 cd/m2
Touch panel
Touchscreen Type5 points capacity TP,G+G
Surface Hardness6H
Interface
USB1*USB(Host),1*Micro USB 5pin
Type C1*Type C (USB3.0/HDMI/Charging)
Audio Output1*3.5mm
HDMI1*HDMI 1.4a Type C
TF Slot1*TF Slot, max: 128G
SIM1*SIM
Power1*DC 5V 3A, Optional: With overvoltage protection, max DC24V
pogo pin1*12 pin pogo pin
OTG cableUSB OTG turn MICRO USB cable  length 45mm
USB  cableUSB turn micro 5P L=1.2M, 4 wires with aluminium foil and shielding
Power Supply
Power AdaptorAC100V ~ 240V,50Hz/60Hz, Output DC 5V/3A
BatteryBuilt-in Li-polymer battery
Capacity: 3.7V/6000mAh
nearly 6hours ( 50% volume sounds, 200 lumens brightness, 1080P HD video display by default )
Operating Environment
IP gradeIP65 waterproof
Drop Height1.22cm  composite wood floors, in operation status
Operate Temperature-10 °C to 50 °C
Store Temperature-20 °C to 60 °C
HumidityHumidity: 95% Non-Condensing
Packing Details
Net weight652g
Gross weight1275g
Product Dimension227.5*150*21mm
Packing size357*186*60mm
Other
Warranty1 year warranty
CertificateCE, FCC, RoHS
Colorblack
Module extension (Optional)
One-dimension barcodeMOTO SE655E100R/Optical resolution: 5mil/scan speed:50 times/s serial port, Code system: UPC/EAN, Bookland EAN ,UCC Coupon Code,ISSN EAN,Code 128,GS1-128,ISBT 128,Code 39,Trioptic Code 39 ,Code 32,Code 93  ,Code 11
Two-dimension barcode Honeywell N3680 hardcode/ Optical resolution:5mil/ scan speed:50 times /s, Code system:PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse
  Maxicode,QR Code, MicroQR, QR Inverse,Aztec,Aztec Inverses,Han Xin,Han Xin Inverse
Optional Accessories
AccessoriesDocking Charger, Hand-strap, Vehicle Mount


R-I81EKH

Model:R-I81EKH
PC
CPUIntel Cherrytrail Z8350, 1.44Ghz-1.92GHz
GPUIntel® HD Graphics
RAM2GB, Optional 4GB
SSD32GB, Optional 64G/128G
G_sensorG_sensor
NFCOptional: NXP NFC 13.56MHz  support ISO/IEC 下14443A/14443B/15693/18092/mifare protocol,identification distance :2-4cm
WIFIAP6255 WIFI 802.11b/g/n/ac   frequency 2.4G+5.8G
BluetoothBT4.2 (BLE) class1  transmited distance:10m
(Bluetooth 5.1 Optional)
3GOptional: IC:H350_A30 frequency:WCDMA(900/2100MHz)  GSM(900/1800MHz),HSDPA 7.2Mbps,HSUPA 5.76 Mbps
4GOptional: EC25-E: LTE FDD: B1/B3/B5/B7/B8/B20 LTE TDD: B38/B40/B41 WCDMA: B1/B5/B8 GSM: B3/B8
GPSOptional: U-blox NEO-7; Capture sensitivity: -160 dBm;Cool Start Time:<50 seconds, Hot start time:<28 seconds,frequency: 0.25 Hz~10 MHz (configurable)
Camerafront 2.0MP with indicator light, rear 5.0MP
SpeakerEmbedded 8Ω/0.8W waterproof speaker*1
MicSensitivity: -42db, Output resistance: 2.2kΩ
Operation Systemwindows 10 S mode/ Pro 32bit 64bit
LCD panel
Panel size8"
Resolution800*1280 IPS
Aspect ratio16:10
Brightness (cd/m²)450 cd/m2
Touch panel
Touchscreen Type5 points capacity TP,G+G
Surface Hardness6H
Interface
USB1*USB(Host),1*Micro USB 5pin
Type C1*Type C (USB3.0/HDMI/Charging)
Audio Output1*3.5mm
HDMI1*HDMI 1.4a Type C
TF Slot1*TF Slot, max: 128G
SIM1*SIM
Power1*DC 5V 3A, Optional: With overvoltage protection, max DC24V
Pogo pinOptional: 1*12 pin pogo pin
OTG cableUSB OTG turn MICRO USB cable  length 45mm
USB  cableUSB turn micro 5P L=1.2M, 4 wires with aluminium foil and shielding
Power Supply
Power AdaptorAC100V ~ 240V,50Hz/60Hz, Output DC 5V/3A
BatteryBuilt-in Li-polymer battery
Capacity: 3.7V/6000mAh
nearly 6hours ( 50% volume sounds, 200 lumens brightness, 1080P HD video display by default )
Operating Environment
IP gradeIP65 waterproof
Drop Height1.22cm  composite wood floors, in operation status
Operate Temperature-10 °C to 50 °C
Store Temperature-20 °C to 60 °C
HumidityHumidity: 95% Non-Condensing
Packing Details
Net weight698g
Gross weight1346g
Product Dimension227.5*150*21mm
Packing size357*186*60mm
Other
Warranty1 year warranty
CertificateCE, FCC, RoHS
Colorblack
Module extension (Optional)
One-dimension barcodeMOTO SE655E100R/Optical resolution: 5mil/scan speed:50 times/s serial port, Code system: UPC/EAN, Bookland EAN ,UCC Coupon Code,ISSN EAN,Code 128,GS1-128,ISBT 128,Code 39,Trioptic Code 39 ,Code 32,Code 93  ,Code 11
Two-dimension barcode Honeywell N3680 hardcode/ Optical resolution:5mil/ scan speed:50 times /s, Code system:PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse
  Maxicode,QR Code, MicroQR, QR Inverse,Aztec,Aztec Inverses,Han Xin,Han Xin Inverse
Optional Accessories
AccessoriesDocking Charger, Hand-strap, Vehicle Mount


Features


1. Robust Durability

When it comes to rugged tablets, durability is of paramount importance. This 8-inch tablet is specifically designed to withstand harsh environments and demanding tasks. Its rugged construction enables it to endure accidental drops, shocks, vibrations, and exposure to dust and water. The device is compliant with industry standards, such as MIL-STD-810G and IP67, ensuring its reliability even in the toughest conditions.

2. Windows 10 Operating System

The tablet runs on the widely acclaimed Windows 10 operating system, offering a familiar and user-friendly interface. With Windows 10, you have access to a vast array of software applications and tools, empowering you to accomplish your tasks efficiently. The intuitive interface and seamless compatibility make this tablet an ideal choice for businesses across various industries.

3. Integrated Barcode Scanner

Efficient barcode scanning is crucial for inventory management, asset tracking, and streamlining workflows. This 8-inch rugged tablet is equipped with a high-performance built-in barcode scanner, enabling you to scan barcodes quickly and accurately. Whether you are in a warehouse, retail store, or field service environment, this feature ensures precise data capture and enhances productivity.

4. Brilliant Display and Touchscreen

The tablet boasts an 8-inch high-resolution display that provides clear and vibrant visuals, even in bright or outdoor settings. The capacitive touchscreen offers responsive and accurate touch functionality, allowing you to navigate through applications with ease. The display is also designed to be viewable from multiple angles, making it convenient for collaborative work or customer interactions.

5. Long Battery Life

To ensure uninterrupted usage throughout the workday, this rugged tablet is equipped with a long-lasting battery. Its efficient power management system optimizes battery usage, enabling you to stay productive without worrying about frequent recharging. The tablet also supports fast charging, minimizing downtime and maximizing efficiency.

6. Connectivity Options

Seamless connectivity is essential for modern business operations. This tablet provides a range of connectivity options, including Wi-Fi, Bluetooth, and optional cellular connectivity, keeping you connected wherever you go. You can access real-time information, collaborate with colleagues, and connect to peripheral devices, such as printers or barcode scanners, effortlessly.

7. Expandable Storage and Processing Power

With ample storage capacity and powerful processing capabilities, this rugged tablet ensures smooth multitasking and efficient data management. The device offers expandable storage options, allowing you to store large amounts of data, documents, and applications. The robust processor ensures quick data processing, enhancing overall performance and productivity.


Applications and Industries


The 8-inch rugged tablet with Windows 10 and a built-in barcode scanner caters to a wide range of industries and applications. Some notable uses include:

1. Warehousing and Logistics

In warehouse and logistics operations, this tablet proves invaluable. The integrated barcode scanner enables efficient inventory management, allowing you to track and locate items accurately. The rugged design ensures durability in fast-paced and demanding warehouse environments, and the device's portability and connectivity options make it an excellent tool for inventory control, order fulfillment, and shipping/receiving tasks.

2. Field Service and Maintenance

Field service professionals greatly benefit from the 8-inch rugged tablet's durability and functionality. Its compact size and robust construction make it suitable for on-site inspections, equipment maintenance, and work order management. The barcode scanner simplifies asset tracking and maintenance history retrieval, ensuring streamlined operations and reduced downtime.

3. Retail and Hospitality

In retail and hospitality settings, this tablet enhances customer service and streamlines operations. The barcode scanner allows for efficient inventory management, price verification, and seamless checkout processes. Additionally, the tablet's connectivity options enable access to real-time information, empowering staff to provide personalized service and accurate product recommendations.

4. Healthcare and Pharmaceutical

The rugged tablet finds utility in healthcare and pharmaceutical industries, where reliability and data accuracy are crucial. Its barcode scanning capabilities aid in medication administration, patient identification, and inventory control. Furthermore, the tablet's robust construction and antimicrobial surface make it suitable for healthcare environments, promoting hygiene and reducing the risk of contamination.


In summary, the 8-inch rugged tablet with Windows 10 and a built-in barcode scanner offers a versatile and durable solution for various industries. Its robust construction, integrated barcode scanner, and powerful features make it an indispensable tool for inventory management, field service tasks, retail operations, healthcare facilities, and more. With its exceptional performance, intuitive interface, and extensive connectivity options, this tablet is poised to enhance productivity, efficiency, and customer satisfaction in your business operations.


For more information or to explore our range of rugged tablets, please visit our website or contact our knowledgeable team of experts. Make the right choice for your business and empower your workforce with the 8-inch rugged tablet with Windows 10 and a built-in barcode scanner.


Elevate Your Business with the 8-Inch Rugged Tablet with Windows 10


Are you an enterprise in need of a powerful and reliable solution to enhance your operations? Look no further than the 8-Inch Rugged Tablet with Windows 10, offered by SHENZHEN SHINHO ELECTRONIC TECHNOLOGY CO., LIMITED. As a manufacturer specializing in Industrial computers, we understand the unique demands of modern industries. Our commitment to integrating resources and technologies allows us to deliver customized industrial panel PCs and touch screen monitors, tailored specifically to meet your requirements.


Unleashing the Power of Customization

At SHENZHEN SHINHO, we pride ourselves on the ability to provide custom solutions to our customers. With an ever-expanding team of experienced engineers and technicians, we possess the strength and expertise necessary to tackle even the most complex challenges. Whether you need a rugged tablet for warehouse management, field service operations, or any other industry-specific application, our commitment to customization ensures that your needs are met precisely.

Extensive Product Range, Core Focus on Customization

Over the years, our product range has evolved from industrial automation solutions to encompass commercial smart terminals, intelligent devices, and human-machine interfaces. However, one aspect remains constant: our core value of customization. The 8-Inch Rugged Tablet with Windows 10 exemplifies this commitment by offering a versatile and durable device that aligns perfectly with your business requirements.

Unmatched Performance and Reliability

Equipped with Windows 10, this rugged tablet delivers a familiar and intuitive user experience. The seamless integration of Windows 10 ensures compatibility with a wide array of software applications, empowering your workforce to accomplish tasks efficiently and effectively. Designed to withstand the rigors of demanding environments, the rugged construction of our tablet ensures robust durability, protecting your investment even in the toughest conditions.

Seamless Connectivity and Enhanced Productivity

Connectivity is essential in today's interconnected world, and our 8-Inch Rugged Tablet excels in this aspect. With built-in Wi-Fi, Bluetooth, and optional cellular connectivity, you can stay connected wherever your business takes you. Real-time information access, collaboration with colleagues, and peripheral device compatibility enable your workforce to maximize productivity and make informed decisions, even on the go.

Unparalleled Versatility and Portability

The 8-Inch Rugged Tablet strikes the perfect balance between functionality and portability. Its compact size and lightweight design make it ideal for various applications, including warehouse management, field service tasks, retail operations, healthcare facilities, and more. Carry it with ease, navigate effortlessly through applications on the responsive touchscreen, and enjoy the convenience of a built-in barcode scanner for efficient data capture.


Trust SHENZHEN SHINHO for Your Rugged Tablet Needs


When it comes to equipping your enterprise with cutting-edge technology, trust SHENZHEN SHINHO ELECTRONIC TECHNOLOGY CO., LIMITED as your partner. With our extensive experience in the industry and unwavering commitment to customization, we are dedicated to providing you with the finest solutions tailored to your specific needs. Elevate your business operations, enhance productivity, and stay ahead of the competition with our 8-Inch Rugged Tablet with Windows 10.


Contact us today to explore the endless possibilities of customization and discover how our rugged tablets can revolutionize your enterprise. Let SHENZHEN SHINHO be your trusted companion on your journey towards success.



Request a Quote
For better quotation, pls include:
Size / Application / Quantity / Special requests
