Functions
Support for Android 10 system.
Integrated 3G / 4G all network communication, WiFi, Bluetooth and other communication modes.
Equipped with 5000mAh large capacity battery, the machine has a endurance of 7 hours.
IP67 high protection level, in accordance with MIL-STD-810G.
Support GPS / GLONASS / Beidou / Galileo, more accurate positioning.
Equipped with front 13 million and rear 16 million pixel auto focus camera.
Support 1D/2D, NFC and other functional modules to meet the application needs of multiple industries.
Specification
| Model:R-T60YL | |
| PC | |
| CPU | MTK OCTA Core |
| OS | Android 10/GMS |
| RAM | 4GB LPDDR4 |
| ROM | 64GB |
| Network connections | |
| WIFI | 2.4G+5G dual frequency, WiFi 802.11(a/b/g/n/ac) |
| Bluetooth | BT5.0 LE |
| 3G/4G | GSM 2/3/5/8 |
| WCDMA 1/2/4/5/8 | |
| TDD B38/B40/B41 | |
| FDD B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/ | |
| B19/B20/B28A/B28B/B18/B25/B26/B66 | |
| Basic parameters | |
| Dimension | 159.7 x 80 x 16.3mm |
| Weight | device unit 275g |
| Device Color | black |
| LCD | 5.7 inch IPS 18:9, 720*1440, 430 Nit |
| Touch Panel | 5 points Capacitive, G+FF |
| Camera | Front 13.0MP Rear 16.0MP |
| I/O | Type C x 1, |
| TF Card x 1 max: 128G, SIM Card x 1 | |
| (Two out of three card holder) | |
| Power | AC100V ~ 240V, 50Hz/60Hz output DC 5V/2.5A |
| GPS | support GPS, GLONASS, Beidou, Galileo |
| Battery | |
| Capacity | 3.8V/5000mAh |
| Type | Built-in Lithium-ion polymer battery |
| Endurance | 7hrs (Default 50% volumn, Default 200 lumens brightness, Play 1080P video) |
| Reliability | |
| Operate Temperature | -10 °C ~ 50 °C |
| Store Temperature | -20 °C ~ 60 °C |
| Humidity | 95% Non-Condensing |
| IP Grade | IP67 |
| Optional modules | |
| NFC | Support ST21NFCDXBGARA7 |
| 1D/2D | Support Honeywell6703, Optional SE4710 |
