Feature:
1. Front aluminum alloy bezel with sandblasting+hard anodizing, UV-protection and Anti-discoloration treatment , front IP65 waterproof and dustproof.
2. Industrial LCD panel, full view angle, 1000nits sunlight readable, with a dimmer for controlling the brightness, can adjust the brightness from 100% to 0.
3. 10-points PCAP touch panel, cover with 2mm tempered glass(Chemically Strengthened) with 7H surface hardness. Anti-glare surface treatment.
4. EETI waterproof solution, the touch function can work well with drop water on the screen.
5.The monitor is built with industrial-grade components, 7x24 continuous operation, wide temperature operation -20 °C ~ 70°C (-4°F ~158°F).
6. Optical bonding, Prevent condensation and fogging inside the screen and increase transmittance
7. With SDI input
Specification:
| Model:SL101 | |
| LCD panel | |
| Panel size | 10.1" |
| Display active area | 216.96(W)x135.6(H) mm / 8.542x5.339 in |
| Resolution | 10280*800 |
| Aspect ratio | 16:10 |
| Brightness (cd/m²) | 1000 nits sunlight readable |
| Brightness control | Dimmer/Knob for dimming |
| Contrast ratio | 900:1 |
| View angle | 85°/85°/85°/85° (R/L/U/D) |
| Support Color | 16.7M |
| Backlight | WLED, 50K hours |
| Touch panel | |
| Touchscreen Type | Non touch |
| Surface Hardness | 7H |
| Surface treatment | Anti glare (chemical etching) |
| Luminousness | ≥85% |
| Touch controller IC | N/A |
| Available touch drivers | N/A |
| Touch optional | Projected Capacitive Touch (up to 10 points ), Resistive touch, IR touch Optional |
| Touch bonding | Optical bonding (Air Bonding optional) |
| External I/O Ports | |
| Video input | 1x HDMI, 1x SDI |
| Audio in/out | 1x 3.5mm Line-out, 1×3.5mm Line-in |
| Touchscreen interface | 1x USB |
| Power connector | 1x 12V DC |
| Power Supply | |
| Working voltage | DC 12V (9-36V DC Optional) |
| Power consumption | 10W |
| Power adapter | AC 100 ~ 240V input and DC [email protected] MAX output, 40W |
| OSD | |
| Function Keys | 5 Keys: Power/Menu/Up/Down/Return |
| Menu Functions | Brightness, Contrast, Screen Setting, Color Temp, OSD Language, Auto Adjust, Reset etc. |
| Support languages | English, Français, Español, Português, Deutsch, Italiano, Nederlands, Svenska, Suomi, Polski, čeština, Русский, 한국어,日本語, 繁體中文，简体中文 |
| Enclosure | |
| Material | Aluminium alloy bezel+ Zinc Plating cold rolled steel rear housing |
| Finish | Front bezel: Sandblasting+Hard Anodizing, UV-protection and Anti-discoloration treatment Rear housing: powder coated |
| Color | Black |
| Mounting | VESA mount 75x75/100x100mm, Panel mount, Flush Mount |
| IP rating | Front panel IP65 |
| Cooling system | Passive - Fanless |
| Operating Environment | |
| Temperature Range | Operating: -20 °C ~ 70°C (-4°F ~158°F) Storage: -30 °C~80°C (-22°F ~176°F) |
| Relative humidity | Up to 90% at all relevant temperatures, non-condensing |
| Vibration | GB/T 2423.10-2019 |
| Shock | GB2423.5 |
| EMC | Class B |
| Packing Details | |
| Weight | Net weight 2.6kg |
| Product Dimension | 300×225×40mm |
| Packing info | 45x43x16cm 4.8kg |
| Accessories | Power adapter, power cord, USB touch cable, HDMI/ VGA/DVI cable, embedded screws |
| Other | |
| Warranty | 1 year warranty |
| Certificates | CE, FCC, RoHS |
Certifications:
Manufacturing process:
Where can Industrial Panel PC SC400X be used?
FAQ:
1)What is the MOQ?
A: MOQ is 1 pcs.
Sample is available for customer to check the quality before bulk order.
2)Do you accept OEM?
A: Yes,OEM and ODM is warmly welcomed.
It is our company’s strength,we can customize the LCD monitor so that can fully meet customers’ requirements.
3)What payment methods does your company accept?
A: T/T, Western Union and Paypal;
4)What’s the delivery time?
A: Sample:5-15 working days. bulk order 15-30 working days.
For customized products,delivery time is negotiable.
We will try our best to meet your delivery time.
5)What are the shipping ways?
A: We will ship the goods according to customer’s demand.
Normally by DHL,UPS,Fedex,TNT.
For bulk order,we also can ship by air,by sea.
