Features
Robust and durable aluminium alloy enclosure, front panel IP65 waterproof and dustproof.
Industrial LCD panel, wide viewing angle, high nits, true color.
Adopt 10 point capacitive touch screen, high precision, durable, anti-interference.
High performance motherboard,7x24 continuous operation.
Support wall mounting, embedded and rackmount etc. apply to a wide range of industrial application.
With wifi, bluetooth.
Etched with AG surface treatment to prevent glare.
Optical bonding, increase the light transmittance.
Specification
Model:SC500A | |
PC System | |
CPU | Rk3288 |
Chipset | Cortex-A17 |
Memory | 2GB DDR3 |
Storage | eMMC 8GB |
Network | 10/100/1000M Base-T Gigabit Ethernet |
OS | Android 5.1 |
Wi-Fi | 2.4G Wi-Fi (WLAN 802.11b/g/n) |
Display interface | Single and double LVDS interface；EDP |
Bluetooth | 4.1 |
battery | 3V battery (CR2032) |
Display Characteristics | |
Design | Open Frame |
| Screen Size | 15.6" ~ 32" |
Panel | LCD, Anti-glare coating |
Native resolution | 1920(H) ×1080(V) (2.1 megapixel Full HD) |
Aspect ratio | 16:9 |
Brightness | 250 cd/m |
LED Life Time | 30,000 Hour |
Contrast Ratio | 3000:1 |
Response Time | 18ms |
Viewing zone | horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89° |
Support Color | 16.7M colors |
Touch | |
Touch technology | projective capacitive |
Touch points | 10 |
Touch accuracy | ±2mm |
Surface Treatment | Anti-glare (chemical etching) |
Touch interface | USB |
Through-Glass | 3mm |
Touch scheme | EETI |
Mechanical | |
Fanless design | yes |
MTBF | 30,000 Hour |
Cable management system | yes |
Operation temperature | 0°C - 50°C |
Storage temperature | - 20°C - 60°C |
Power Management | |
Power supply unit | External |
Power supply | DC 12V |
Rated output current | 3A |
Installation Method | |
VESA | 100mm*100mm Mounted at side |
External Connectors | |
DC-In | ×1 |
HDMI | ×1 |
USB | ×2 |
Audio | ×1 |
Sim card | ×1 |
TF card | Support 32GB |
Wi-Fi | 2.4G Wi-Fi (WLAN 802.11b/g/n) |
Com | ×2 |
Internal Connectors | |
DC IN | ×1 |
USB | ×4 |
Serial | ×1 |
Speaker | ×1 |
IR&LED | ×1 |
Power Keyer | ×1 |
DEBG | ×1 |
LDVS | ×1 |
UART TTL | ×1 |
KEY | ×1 |
12C Control | ×1 |
GPIO | ×1 |
BL Control | ×1 |
EDP | ×1 |
SPK | ×1 |
MIC | ×1 |
| PCI_E | ×1 |
