Industrial Android Tablet PC SC215W Feature:
1. Aluminum alloy face frame and heat sink are sandblasted and oxidized, UV-resistant and anti-discoloration, Full IP65 waterproof
2. Industrial-grade LCD screen, full viewing angle, 1000 brightness sunlight readable, automatic light sensor to adjust brightness
3. 10-point capacitive touch screen, the protective layer is 2mm tempered glass (chemically strengthened), and the hardness reaches 7H
4. EETI touch control solution, touch well when water drop on the touch screen
5. Optical bonding between LCD and touch screen
6. Built-in 70000mAh battery, which can work continuously for more than 12 hours
7. The opening design on the heat sink can be installed and replaced with a SIM card
8. Two Type-C waterproof interfaces
9. Front 8MP/4K camera
10. Adopting industrial-grade components, 7x24 hours of work, supporting wide temperature operation -20-70℃
11. The front frame and the back shell are sealed with waterproof tape, and the machine can be disassembled for inspection and repair without affecting the waterproof performance
Industrial Android Tablet PC SC215W Specification:
| PC | |
| CPU | RK3588, Cortex-A76+Cortex-A55 octa-core 64-bit 2.4GHz |
| GPU | Mali-G610 MC4 |
| NPU | 6TOPS AI computing power, triple-core architecture, support int4/int8/int16/FP16/BF16/TF32 |
| Memory | 2G/4G /8G Optional |
| Storage | eMMC 16G/32G/64G/128G Optional |
| Vedio | Support H.265/H.264/AV1/VP9/AVS2 video decoding, up to 8K@60FPS; support H.264/H.265 video encoding, up to 8K@30FPS |
| Display | Supports multiple displays, up to 8K@60FPS; supports EDP/DP/HDMI2.1/MIPI multiple display interfaces* |
| Video input | Supports multi-camera input (4*4lanes or 4*2lanes+2*4lanes) MIPI CSI-2 and DVP interfaces; 32MP ISP, supports HDR and 3DNR; supports HDMI2.0 input, up to 4K@60FPS |
| Network | 2 port 10/100/1000M Adaptive Ethernet RJ45 connector + 4-Pin POE header |
| Operation System | Android 12 |
| Play Modes | Support timing, loop and spots etc. play modes |
| Wireless Network Support | WIFI, 3G, 4G , TD-LTE, GPS optional |
| Image Format | JPG/BMP/GIF/TIFF/PNG |
| Video Format | RMVB,FLV,MPEG1/2/4, AVI, WMV, MOV, MP4, TS etc. |
| Camera | Build in Camera 8MP/4K |
| Battery | Build in battery 70000mAh |
| RTC Real Time Clock | YES |
| I/O | |
| USB | 2x IP65 USB3.0 (1x HOST, 1x OTG) 2x IP65 Type-C |
| LAN | 1x IP65 RJ45 |
| Audio | 1x IP65 AUDIO 1x IP65 Speaker 1x IP65 MIC Input |
| Video Outputs | 1x IP65 HDMI |
| Power input | 1x IP65 Battery charging port |
| Other | 1*IP65 WIFI antenna jack male 1*IP65 BT antenna jack male 1*IP65 4G antenna jack male 1*IP65 Power on/off button |
| LCD panel | |
| Panel size | 21.5" |
| Display active area | 344.232(W)x193.536(H) mm / 13.552x7.62 in |
| Resolution | 1920*1080 |
| Aspect ratio | 16:9 |
| Support Color | 16.7M colors |
| Brightness (cd/m²) | 1000 nits, sunlight readable |
| Brightness control | PWM software adjustment |
| Contrast ratio | 800:1 |
| View angle | 85°/85°/85°/85° (R/L/U/D) |
| Backlight | WLED, 50K hours |
| Touch panel | |
| Touchscreen Type | 10 point capacitive touch |
| Surface hardness | 7H |
| Touch response time | <5ms |
| Surface treatment | Anti glare (chemical etching) |
| Luminousness | ≥80% |
| Touch controller IC | EETI 81 |
| Available touch drivers | Windows, Linux, Android, Mac, etc |
| Touch bonding | Air bonding (Optical bonding optional) |
| Touch options | 5 wire resistive touch, non touch, IR touch optional |
| Power Supply | |
| Working voltage | DC 12V (9-36V DC Optional) |
| Power consumption | 40W |
| Power adapter | AC 100 ~ 240V input and DC +12V@5A MAX output, 60W |
| Enclosure | |
| Material | Aluminum alloy panel, heat sink plate + galvanized cold-rolled plate back shell |
| Finish | Aluminum frame, aluminum heat sink: sandblasting oxidation, anti-UV and anti-discoloration treatment Rear shell: electrostatic powder spraying |
| Color | Black, other color optional |
| Mounting | VESA mount 75x75/100x100mm |
| IP grade | Full IP65 waterproof |
| Cooling system | Passive - Fanless |
| Operating Environment | |
| Temperature Range | Operating: -20 °C ~ 70°C (-4°F ~158°F) Storage: -30 °C~80°C (-22°F ~176°F) |
| Relative humidity | Up to 100% at all relevant temperatures, non-condensing |
| Vibration | GB/T 2423.10-2019 |
| Shock | GB2423.5 |
| EMC | Class B |
| Packing Details | |
| Net weight | Net weight 13.2kg |
| Product Dimension | 536.5×2329.6×106mm |
| Packing info | 1pc/ctn 73×48×20cm 17kg 2pcs/ctn 75×49×42cm 35kg |
| Accessories | Power supply, Power plug, waterproof network cable, waterproof USB cable, waterproof HDMI cable, Antenna |
| Other | |
| Warranty | 1 year warranty |
| Certificate | CE, FCC, RoHS |
Available Sizes:
| Size | Resolution | Aspect ratio | Touch type |
| 10.1" | 1366*768 | 16:9 | no touch/capacitive/resistive |
| 10.4" | 1024*768 | 4:3 | no touch/capacitive/resistive |
| 11.6" | 1920*1080 | 16:9 | no touch/capacitive |
| 12.1" | 1024*768 | 4:3 | no touch/capacitive/resistive |
| 12.1" | 1280*800 | 16:10 | no touch/capacitive |
| 15" | 1024*768 | 4:3 | no touch/capacitive/resistive |
| 15.6" | 1920*1080 | 16:9 | no touch/capacitive/resistive |
| 17" | 1280*1024 | 5:4 | no touch/capacitive/resistive |
| 17.3" | 1920*1080 | 16:9 | no touch/capacitive/resistive |
| 19" | 1280*1024 | 5:4 | no touch/capacitive/resistive |
| 19" | 1440*900 | 16:10 | no touch/capacitive/resistive |
| 21.5" | 1920*1080 | 16:9 | no touch/capacitive/resistive |
Components:
-Package included: Industrial Android Tablet PC, power adapter and power cord;
-Accessories or Parts: User manual, warranty card;
Certifications:
Quality Inspection:
FAQ:
1)What is the MOQ?
A: MOQ is 1 pcs.
Sample is available for customer to check the quality before bulk order.
2)Do you accept OEM?
A: Yes,OEM and ODM is warmly welcomed.
It is our company’s strength,we can customize the LCD monitor so that can fully meet customers’ requirements.
3)What payment methods does your company accept?
A: T/T, Western Union and Paypal;
4)What’s the delivery time?
A: Sample:5-15 working days. bulk order 15-30 working days.
For customized products,delivery time is negotiable.
We will try our best to meet your delivery time.
5)What are the shipping ways?
A: We will ship the goods according to customer’s demand.
Normally by DHL,UPS,Fedex,TNT.
For bulk order,we also can ship by air,by sea.
