Features:
1. Full IP66 sealed stainless steel enclosure.
2. Support media player by USB stick and controlled by remote.
3. Industrial LCD panel, wide viewing angle, true color.
4. Brightness upto 1000 nits, sunlight readable.
5. Covered with 3mm AF glass, anti-fogging, anti-fingerprint.
6. High performance motherboard, 7x24 continuous operation.
7.Acid-resistant, alkali-resistant, corrosion-resistant.
Specification:
| LCD panel | |
| Panel size | 21.5" |
| Resolution | 1920*1080 |
| Aspect ratio | 16:9 |
| Support Color | 16.7M colors |
| Brightness (cd/m²) | 400+ cd/m² |
| Contrast ratio | 1000:1 |
| View angle | 80°/80°/80°/80° (R/L/U/D) |
| Customization | Covered 3mm Anti-fogging glass |
| Signal Ports | |
| VGA | 1x VGA |
| DVI | 1x DVI |
| HDMI | optional |
| Audio in/out | optional |
| OSD in the front bezel | |
| OSD control | Brightness, contrast ratio, auto adjustment, H/V position, language select, etc. |
| Support languages | English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese, etc. |
| Support OS | Windows XP, Windows /7/8/10, Linux, Mac OS X, Android, ect. |
| Power Supply | |
| External Power Supply | AC 100 - 240V, 50-60Hz |
| Working voltage | DC 12V |
| Power consumption | ≤35W |
| Enclosure | |
| Material | Stainless steel 304 |
| Color | Silver |
| VESA mounting | 100x100mm |
| IP grade | Full IP66 |
| Operating Environment | |
| Temperature Range | operating: -30 to 85°C, storage: -30 to 85°C |
| Relative humidity | operating: 10% to 80%, storage: 5% to 90% |
| Packing Details | |
| Net weight | 7KG |
| Gross weight | 10KG |
| Product Dimension | 53.16*32.82*5.74cm |
| Packing size | 74x45x19 cm |
| Accessories | IP66 waterproof Power adapter, waterproof VGA and DVI cables, remote control |
| Other | |
| Customization | Built-in media player by USB stick, controlled by remote |
| Mounting | VESA mounting |
| embedded mounting screws (optional) | |
| desk stand holder (optional) | |
| Warranty | 1 year warranty |
| Certificates | CE, FCC, RoHS |
Available Sizes:
| Size | Resolution | Aspect ratio | Touch type |
| 10.1" | 1280*800 | 16:10 | capacitive/resistance |
| 12.1" | 1024*768 | 4:3 | capacitive/resistance |
| 15" | 1024*768 | 4:3 | capacitive/resistance |
| 15.6" | 1920*1080 | 16:9 | capacitive/resistance |
| 17" | 1280*1024 | 5:4 | capacitive/resistance |
| 19" | 1280*1024 | 5:4 | capacitive/resistance |
| 21.5" | 1920*1080 | 16:9 | capacitive/resistance |
| 22" | 1920*1080 | 16:9 | capacitive/resistance |
| 24" | 1920*1080 | 16:9 | capacitive/resistance |
| 27" | 1920*1080 | 16:9 | capacitive/resistance |
