Features
Full Aluminum alloy enclosure, compact, low weight design, excellent heat dissipation.
Sealed construction full IP65 waterproof , fanless design, noiseless, low-power consumption design.
Suitable for harsh operating environment , dustproof, anti-corrosion, shockproof, anti-vibration.
High performance motherboard, 7x24 continuous operation.
Wide operating temperature support (-20°C~70°C).
With high electromagnetic compatibility and anti-interference capacity.
Expanded displays for Multi-task. Auto boot, remote wakening support.
Specification
| Model: SM701-3 | |
| PC | |
| CPU | Intel® Core I7-6500U, dual core, 2.5GHz, Fanless |
| Chipset | Intel® Skylake-U series SOC |
| Memory | 8G DDR4 (2G,4G, optional) |
| Hard Drive Capacity | 256G SSD (32G,64G,128GB SSD optional) |
| Graphics | CPU Integrated graphics HD Graphics and support 1080p HD photo quality |
| Network | 2×Realtek RTL 8111E Gigabit Ethernet controller |
| Front I/O Ports | 4*USB, 2*RJ45, 1*DC in,1*Power Button |
| Rear I/O Ports | 3*COM, 1*HDMI, 1*VGA |
| Resolution support | above 800*600 |
| Hd support | 1080P |
| Operation System | Support Windows 7/8/10, Linux, Ubuntu, Debian etc. |
| Power Supply | |
| External Power Supply | AC 100 - 240V |
| Working voltage | DC 24V |
| Power consumption | ≤45W |
| Enclosure | |
| Material | Aluminum Alloy |
| Color | Black, Silver, white, colors can be customized |
| Operating Environment | |
| Temperature Range | operating: -20 to 70°C, storage : -30 to 80°C |
| Relative humidity | 20%~95% @ 40° C, non-condensing |
| Vibration | 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
| Packing Details | |
| Net weight | 2.5kg |
| Gross weight | 5kg |
| Product Dimension | 21.4*20.4*5.2cm |
| Packing size | 43*38*19mm |
| Accessories | Power adapter, full IP65 waterproof cable sets |
| Other | |
| Mounting (options) | Built-in mounting bracket |
| wall/desking mounting brackets (optional) | |
| Warranty | 1 year warranty |
