Features
Intel 11 generation -H, 12 generation -H, 13 generation -H
The exclusive RTX3060 comes with 12GB of video memory
Supports up to 64GB memory
HDMI 2.0x3, USB TYPE-C, supports 4x 4K displays
Dual NVME
Dual 2.5G ethernet
Specification
| Model: SM16 | |
| PC | |
| CPU Optional | Intel® Core i9-11900H, 8 Cores, 16 Threads, Turbo Frequency 4.9GHz |
| CPU Optional | Intel® Core i7-12800H, 14 Cores(Performance-core 6, Efficient-core 8), 20 Threads, Turbo 4.8GHz |
| Memory | 11gen: 2x DDR4 SODIMM, Max 64GB 12/13gen: 2x DDR5 SODIMM, Max 64GB |
| Storage | 2 x M.2 2280 NVME |
| Display | 3 x HDMI 2.0 |
| Network | 1 x GbE RJ45 RTL8111H |
| I/O | 5 x USB3.2 Gen2 (10Gb)，2 x USB2.0，1 x USB3.2 Gen2 Type-C (10Gb) 1 x SD 3.0/4.0/7.0 Card 3 x HDMI 2.0, 1 x USB Type-C，support 4x 4K display 1 x Power Button 12-19V DC INPUT 2x Audio in/out jack |
| Expansion Slot | 1 x M.2 2232 WIFI |
| Operation System | Windows® 10/11, LINUX |
| Power Supply | |
| External Power Supply | AC 100 - 240V |
| Working voltage | DC 12-19V |
| Power consumption | ≤20W |
| Enclosure | |
| Material | Aluminum Alloy +ABS |
| Color | Black |
| Operating Environment | |
| Temperature Range | Operating: -20 to 60°C, Storage: -30 to 70°C, surface air flow |
| Relative humidity | 10%~95% , non-condensing |
| Packing Details | |
| Net weight | 1.5 kg |
| Gross weight | 3 kg |
| Product Dimension | 228.8 x 148 x 56.8 mm |
| Packing size | 30*20*15cm |
| Accessories | Power adapter |
| Other | |
| Mounting (options) | Desktop installation |
| Wall mounting | |
| Warranty | 2 years warranty |
