Specification
| PC | |
| CPU | Intel® Xeon E2100 |
| CPU Optional | Other CPU Optional |
| Chipset | Intel® C621 |
| Display | Onboard display chip |
| UPI | 2UPI, Max 10.4 GT/s |
| Memory | 8 x DDR4 SO-DIMM max 2TB LRDIMM, Maz 2933MT/s |
| Storage | 4xSATA 3.5/2.5 inch Hot Replaceable optional, SAS hard disk optional Supports built-in 2* 2.5-inch SSD and 1* M.2 PCI-E SSD |
| RAID Optional | Optional Support RAID 0, 1, 10, 5, only supported under Windows Optional supports RAID 0, 1, 5, 6, 10, 50, 60, etc., supports Cache supercapacitor protection, and provides functions such as RAID level migration, hot spare disk, and online expansion. |
| Network | Supports 2*Gigabit network electrical ports, supports 1*Gigabit network management interface Optional dual Gigabit/10Gb, four Gigabit/10Gb and dual 25Gb Ethernet cards, etc. |
| Optional | Optional Notebook DVD-ROM/DVD-RW |
| PCIE-E | 1* PCIE-E 3.0X8 Slot (FHFL/Single width) |
| I/O | 4*USB2.0, 2* USB2.0 2* LAN 1* LAN for remote control manage 1*VGA 1×SIM card slot |
| Support System | Windows 8.1/10 64bit, Windows Server 2012/2018/2022 R2/201664bit RedHat Enterprise Linux Server 6.9/7.3/7.4 64bit, CentOs 6.9/7.3/7.4 64bit Ubuntu 16.10/17.104 64bit, VMWare ESXi 6.5 U1 |
| Power | 100-240 V AC IN, 400W (250W Optional) |
| Working temperature | 10~ + 40℃ |
| NON Working temperature | -10~ + 60℃ |
| Working humidity | 5%~95% relative humidity, non-condensation state |
| Dimension | 430x43.5x660mm |
