Features:
All aluminum alloy structure
Onboard 12th generation Intel® Core™ processor
Support 3 HDMI high-definition display interfaces, support synchronous/asynchronous three displays
Supports 3 M.2 slots (can support SSD + WIFI + 4G/5G at the same time)
Support 2 COM ports (2 optional RS232/485 mode)
Support DC 12V input (9-36V DC Optional)
Low power fanless
Industrial grade working temperature -25℃~70℃
Specification
| Model: SM02 | |
| PC | |
| CPU Optional | Intel® Core i3 1215U, 6 Cores, 8 Threads, Turbo 4.4GHz, Fanless |
| CPU Optional | Intel® Core i5 1235U, 10 Cores, 12 Threads, Turbo 4.4GHz, Fanless |
| CPU Optional | Intel® Core i7 1255U, 10 Cores, 12 Threads, Turbo 4.7GHz, Fanless |
| Memory | 1xDDR5 4800 SODIMM, Max 32GB |
| Storage | 1x M.2 2280 slot, 1x 2.5-inch SATA |
| Display | 3x HDMI Supports synchronous/asynchronous three displays, resolution up to 4096x2160 |
| Display chip | Intel(R) UHD Graphics |
| Network | 3x Intel i225-V 100/1000/2500M Ethernet |
| I/O | 3x HDMI, 2x COM(RS232, RS485 Optiona), 3x LAN, 1x Audio, 1x button On/off, 1x SIM card slot, 4x USB3.1, 1x DC |
| Expansion Slot | Supports 1x M.2 2280 M-Key slot (NVME protocol) Supports 1x M.2 3052 B-key slot (USB3.0 signal, supports 4G/5G), external SIM card slot Supports 1x M.2 2230 E-key slot (supports WIFI, Bluetooth) Expandable interface (standard shipment does not include this interface): 2 USB2.0, 4-way GPIO |
| BIOS | AMI EFI BIOS |
| WDT | Support hardware reset (256 level, 0-255 sec) |
| TMP 2.0 | TPM2.0 security encryption |
| Other | Power on, scheduled boot, wake-on-LAN, PXE boot, watchdog (level 0~255), TPM2.0 security encryption |
| Operation System | Windows® 10/11, LINUX etc |
| Power Supply | |
| External Power Supply | AC 100 - 240V |
| Working voltage | DC 12V |
| Power consumption | ≤20W |
| Enclosure | |
| Material | Aluminum Alloy |
| Color | Metal gray |
| Operating Environment | |
| Temperature Range | Operating: -20 to 60°C, Storage: -30 to 70°C, surface air flow |
| Relative humidity | 5%~95% , non-condensing |
| Packing Details | |
| Net weight | 1.1 kg |
| Gross weight | 2.5 kg |
| Product Dimension | 170 * 140 * 58 mm |
| Packing size | 30*20*12cm |
| Accessories | EU/UK/US Power plug, Power adapter, 2.5-inch hard drive bracket, Certificate, Warranty card, VESA bracker |
| Other | |
| Mounting (options) | Wall mounting |
| Embedded mount | |
| Warranty | 2 years warranty |
