The Sihovision Sunlight Readable Industrial Monitor have a high-resolution 1600*1200 TFT-LCD, High brightness 1000 nits. A wide selection of display sizes are available from 8" to 27" with a format aspect of 4:3 and 16:9, and selected touch type.
Sunlight Readable Industrial Monitor with dimmer for controlling the brightness, can adjust the brightness from 0 to 100%.
Logos, colors of aluminum front bezel, back cover can be customized to fit in customer's equipment or surroundings.
Main Features
Material: Stainless steel 316.
Industrial 20.1'' LCD panel, 1600*1200 resolution, wide viewing angle, high nits, true color.
Cover with 4MM tempered glass, front panel IP67 waterproof.
Black nailpaint on all screws, and with stop slice.
High brightness 1000 nits, sunlight readable.
With dimmer for controlling the brightness, can adjust the brightness from 100% to 0.
High performance mainboard, 7x24 continuous operation.
9-36V DC.
Specification
| Model:SL201 | |
| LCD panel | |
| Panel size | 20.1" |
| Resolution | 1600*1200 |
| Aspect ratio | 4:3 |
| Support Color | 16.7M colors |
| Brightness (cd/m²) | 1000 nits |
| Brightness control | Manual dimmer |
| Contrast ratio | 1000:1 |
| View angle | 80°/80°/80°/80° (R/L/U/D) |
| Signal Ports | |
| VGA | 1x VGA |
| DVI | 1x DVI |
| HDMI | 1x HDMI |
| Audio in/out | Optional |
| OSD | |
| OSD control | Brightness, contrast ratio, auto adjustment, H/V position, language select, etc. |
| Support languages | English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese, etc. |
| Support OS | Windows XP, Windows /7/8/10, Linux, Mac OS X, Android, etc. |
| Power Supply | |
| External Power Supply | AC 100 - 240V, 50-60Hz |
| Working voltage | DC 12V |
| Power consumption | ≤45W |
| Enclosure | |
| Material | Stainless steel 316 |
| Color | Ink Black |
| VESA mounting | 100x100mm |
| IP grade | Front panel IP67 waterproof |
| Operating Environment | |
| Temperature Range | Operating: -20 to 70°C, storage: -20 to 80°C |
| Relative humidity | Operating: 10% to 80%, storage: 5% to 90% |
| Packing Details | |
| Net weight | 11kgs |
| Gross weight | 12.4kgs |
| Product Dimension | 49*40*6.15cm |
| Packing size | 65.5*17*61cm |
| Accessories | Power adapter, power cord, HDMI cable, embedded screws |
| Other | |
| Mounting | Embedded mounting screws |
| Wall mounting brackets (optional) | |
| Desk stand holder (optional) | |
| Warranty | 1 year warranty |
| Certificates | CE, FCC, RoHS |
Available Sizes:
| Size | Resolution | Aspect ratio | Touch type |
| 10.1" | 1280*800 | 16:10 | capacitive/resistance |
| 12.1" | 1024*768 | 4:3 | capacitive/resistance |
| 15" | 1024*768 | 4:3 | capacitive/resistance |
| 15.6" | 1920*1080 | 16:9 | capacitive/resistance |
| 17" | 1280*1024 | 5:4 | capacitive/resistance |
| 19" | 1280*1024 | 5:4 | capacitive/resistance |
| 21.5" | 1920*1080 | 16:9 | capacitive/resistance |
| 22" | 1920*1080 | 16:9 | capacitive/resistance |
| 24" | 1920*1080 | 16:9 | capacitive/resistance |
| 27" | 1920*1080 | 16:9 | capacitive/resistance |
